The IMBQ-HP-V2 Pan/tilt tracking mount offers larger bearings and more accurate encoders than the IMBQ-STND. The IMBQ-HP-V2 supports a 100kg multi-sensor payload and 13-arcssecond accuracy while maintaining 90 deg/sec closed loop tracking.
The IMBQ pan/tilt chassis is precision milled from solid block of high grade 6000 series aluminium. This process ensures there are no material flaws, minimal chassis flex, and orthogonality for increased accuracy.
Like all IMAGO tracking mount the IMBQ-HP-V2 is designed to avoid parallax errors, this offers a real world accuracy advantages over our competitors.
Tracking Mount Specifications
| Description | Performance |
|---|---|
| Payload | 100kg/220lbs |
| Weight | ~85lbs |
| Azimuth Range | 360 deg |
| Elevation Range | 360 deg |
| IMBQ Accuracy | 13arcsec |
| HP Repeatablity | 7 arcsec |
| Max. Acceleration | 180 deg/sec^2 |
| Max Velocity | 90 deg/sec |
| Min Velocity | 0.02 deg/sec |
| Encoder Resolution | 20 bit |
